| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P2-311111 |
| Series: | P2 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 3 |
| Illumination: | Not Illuminated |
| Contact Configuration: | 2 SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .46 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 125 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP2-311111 |
P2-311111
Specifications
Detailed Description
Introducing the P2 Series Button Switch ( P2-311111), a reliable and durable solution for your panel mounting needs. With a sleek black aluminum case and a vibrant red button cap, this switch is not only visually striking but also highly functional. Featuring a 2 SPST-NO contact configuration with silver-plated brass contacts, it guarantees a current rating of 5A at 125VAC or 28VDC. The Off-(On) switch function, along with a sealed housing and IP3 rating, ensures optimal performance even in challenging environments. Operating smoothly between -55°C to 85°C, and boasting a durability rating of 25,000 cycles, this switch is designed to last. Perfect for a wide range of applications, especially where reliability is paramount. Upgrade to the P2 Series Button Switch for seamless control and peace of mind.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
