| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-31241 |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NC |
| Actuator Type: | Button (Flat Push/Pull) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .56 in |
| Switch Function: | ON-OFF |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-31241 |
P3-31241
Specifications
Detailed Description
Introducing the P3-31241, a rugged and dependable Sealed Momentary Action Pushbutton from the P3 series. With a sleek red cap and durable silver case, this switch is designed for longevity in demanding environments, boasting an IP6K4S rating for dust and water resistance. The flat push/pull button with a round actuator offers easy operation, while the brass contacts with silver plating ensure reliable performance. Suitable for panel mounting and featuring solder termination, it's ideal for various applications. Operating at up to 115VAC and 28VDC with a current rating of 10A, this SPST-NC switch guarantees efficient power control. From industrial machinery to automotive systems, trust the P3-31241 for seamless and secure switching.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
