| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-32115W |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Green |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-32115W |
P3-32115W
Specifications
Detailed Description
Introducing the P3 Series Sealed Momentary Action Pushbutton Switch, SKU P3-32115W. This durable and reliable switch is designed for demanding environments, with an IP6K8S rating for water and dust resistance. The green button, housed in a sleek silver casing, boasts a flat round actuator for easy operation. Ideal for panel mounting, it features a screw termination and is constructed with high-quality materials including brass contacts and aluminum housing. With a current rating of 10A and voltage ratings of 115VAC/28VDC, this SPST-NO switch guarantees efficient performance. Operating smoothly in temperatures ranging from -55°C to 85°C, it offers a lifespan of 100,000 cycles. Perfect for industrial applications, the P3 Series ensures precise and durable functionality.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
