| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-32212 |
| Series: | P3 |
| Cap Color: | Black |
| IP Rating: | IP6K4S |
| Case Color: | Silver |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-OFF |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NC |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP3-32212 |
P3-32212
Specifications
Detailed Description
Introducing the P3-32212, a high-performance push button switch from the P3 series. With a sleek design featuring a black button cap and silver case, this switch is not only visually appealing but also durable, boasting a 100,000 cycle lifespan. The IP6K4S rating ensures its reliability even in harsh environments. Perfect for panel mounting, it has a current rating of 10A and operates at both 115VAC and 28VDC. The momentary action, SPST-NC contact configuration, and brass contact material guarantee precise and efficient functionality. Whether in industrial machinery or consumer electronics, this sealed push button switch is a dependable choice for applications requiring a robust and long-lasting control solution.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
