| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-61123 |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat Push/Pull) |
| Case Color: | Silver |
| Actuator Material: | Nylon |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Orange |
| Actuator Length: | .38 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-61123 |
P3-61123
Specifications
Detailed Description
Introducing the P3-61123, a high-performance sealed momentary action pushbutton switch designed for durability and reliability in demanding environments. Featuring a flat push/pull button with a round shape and a vibrant orange cap, this switch stands out for its IP6K4S ingress protection rating and rugged aluminum housing. The SPST-NO contact configuration ensures seamless operation, with a 10A current rating for efficient power handling. Ideal for panel mounting, the P3-61123 offers solder termination and a maximum operating temperature of 85°C, making it suitable for a wide range of applications. Trust in its 100,000 cycle durability rating and brass contact material for long-lasting performance. Upgrade your control systems with this essential component from the P3 series.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
