| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-71111 |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Nylon |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-71111 |
P3-71111
Specifications
Detailed Description
Introducing the P3-71111, a high-performance P3 series push button switch designed for rugged applications. Featuring a durable red button with a flat, round actuator, this switch is perfect for panel mounting in industrial settings. With an IP6K4S sealing rating and a housing made of robust aluminum, it ensures reliable operation even in harsh environments. The SPST-NO contact configuration, along with silver contact plating and a brass contact material, guarantees efficient and long-lasting performance. Rated for 10A at 115VAC and 28VDC, this switch is suitable for a wide range of power applications. Whether you're in need of a dependable push button switch for machinery or equipment, the P3-71111 delivers uncompromising quality and durability.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
