| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-81127 |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Nylon |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Violet |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-81127 |
P3-81127
Specifications
Detailed Description
Introducing the P3-81127, a durable and reliable Sealed Momentary Action Pushbutton switch designed for high-performance applications. Featuring a sleek Silver case with a Violet cap, this switch offers a 10A current rating and is panel mountable for easy installation. The IP6K4S rating ensures protection against dust and water ingress, while the SPST-NO contact configuration guarantees efficient operation. With a wide operating temperature range of -55°C to 85°C, this switch is suitable for use in various environments. Constructed with a Brass contact material and Aluminum housing, it provides long-lasting durability, with a lifespan of 100,000 cycles. Whether in industrial machinery or automotive systems, the P3-81127 is the ideal choice for reliable and efficient control.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
