| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-82215 |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NC |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Nylon |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Green |
| Actuator Length: | .25 in |
| Switch Function: | ON-OFF |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-82215 |
P3-82215
Specifications
Detailed Description
Introducing the P3-82215, a high-performance push button switch from the P3 series. Featuring a durable aluminum housing with a sleek silver case, this switch is designed for reliability in demanding environments. The green flat button actuator, made of nylon, ensures comfortable operation while the IP6K4S rating guarantees protection against dust and water ingress. With a current rating of 10A and a contact configuration of SPST-NC, it offers precise control. Ideal for panel mounting with screw termination, this sealed momentary action switch is perfect for applications requiring a dependable and long-lasting solution. Operating smoothly in temperatures ranging from -55°C to 85°C, it is suitable for a wide range of industrial and commercial uses. Trust the P3-82215 for efficient and hassle-free switching.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
