| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-128121 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | 4PDT 16 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .16 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-128121 |
P4-128121
Specifications
Detailed Description
Introducing the P4 Series two-step custom pushbutton switch, featuring a striking red cap and sleek black case design. With a durable aluminum housing and thermoplastic actuator, this sealed switch ensures reliable performance in various environments. The 4PDT 16 terminal configuration with gold-plated brass contacts guarantees excellent conductivity, while the 5A current rating and 28VDC voltage rating make it suitable for a range of applications. The button's flat, round actuator shape offers comfortable operation, with a 25,000-cycle durability rating for long-lasting use. Ideal for panel mounting with solder termination, this non-illuminated switch is perfect for industrial and commercial settings, offering precise momentary action control. Experience premium quality and functionality with the P4 Series pushbutton switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
