| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-213121 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Silver |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | DPDT 6 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-213121 |
P4-213121
Specifications
Detailed Description
Introducing our Auxiliary Actuators, the P4 series, featuring a distinctive red cap and a durable silver casing. With an IP6K4S rating, these sealed push buttons ensure reliable performance in demanding environments. The flat round button design offers a comfortable actuation experience, while the gold-plated contacts and silver contact material guarantee efficient conductivity. Ideal for panel mounting with PC pin termination, these switches boast a high durability rating of 25,000 cycles. Operating at up to 115VAC and 28VDC, with a DPDT 6 Terminal contact configuration, they provide versatile functionality. Whether in industrial or commercial settings, our P4213121 switches offer precision control with a two-step custom push button mechanism, making them a reliable choice for various applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
