| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-323226 |
| Series: | P4 |
| Cap Color: | Blue |
| IP Rating: | IP6K4S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Contact Material: | Silver |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | DPDT 6 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP4-323226 |
P4-323226
Specifications
Detailed Description
Introducing the P4-323226 Push Button Switch, a durable and reliable component designed for high-performance applications. Featuring a sleek black aluminum case with a blue button, this switch is not only visually appealing but also built to withstand tough environments with its IP6K4S sealing. The DPDT 6 Terminal configuration offers versatility in connectivity, while the gold-plated contacts ensure optimal conductivity. With a 5A current rating and operating temperatures ranging from -40°C to 85°C, this switch is perfect for use in various industrial settings. The flat round button actuator provides a comfortable interface for users, making it ideal for situations that require frequent activation. Trust in the P4-323226 for seamless and efficient control in your electronic systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
