| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-412122 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Silver |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPDT 4 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-412122 |
P4-412122
Specifications
Detailed Description
Introducing the P4-412122, part of the P4 series, a high-performance push button switch designed for durability and reliability. With a sleek black cap and case, this switch features a flat round button actuator for comfortable use. Operating at a maximum of 28 VDC and 5 A, it is suitable for a wide range of applications. The gold-plated silver contacts ensure excellent conductivity, while the aluminum housing guarantees robustness. With a sealed design and PC pin termination, it offers enhanced protection against environmental factors. Ideal for industrial and commercial settings, this switch is rated for 25,000 cycles and can withstand temperatures from -40°C to 85°C. Upgrade your control systems with this premium-quality push button switch, perfect for demanding environments.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
