| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-413122 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Silver |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | DPDT 6 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-413122 |
P4-413122
Specifications
Detailed Description
Introducing the P4 series Auxiliary Pushbutton Switch ( P4-413122), designed for precise control in critical applications. With a sleek black aluminum housing and matching button, this switch offers a stylish and durable solution. The flat round actuator ensures comfortable operation, while the gold-plated contacts guarantee reliable conductivity. Featuring a DPDT 6 Terminal configuration and a 5A current rating, it's ideal for handling complex circuit requirements. Its sealed design and PC pin termination make it suitable for a variety of environments. With a lifespan of 25,000 cycles, this switch is built to last. Perfect for panel mounting, it operates flawlessly in temperatures ranging from -40°C to 85°C, with a voltage rating of 28VDC. Upgrade your control systems with the P4 Auxiliary Pushbutton Switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
