| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-424112 |
| Series: | P4 |
| Cap Color: | Black |
| Case Color: | Silver |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Contact Material: | Silver |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | DPDT 8 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP4-424112 |
P4-424112
Specifications
Detailed Description
The P4-424112 Push Button Switch, part of the P4 series, is meticulously crafted for reliable performance in demanding applications. Featuring a sleek black cap and durable silver case, this non-illuminated switch offers a tactile button with a round, flat actuator for precise control. With a current rating of 5A, gold-plated contacts, and a sealed housing made of aluminum, it ensures long-lasting operation, even in harsh environments. The DPDT 8 terminal configuration and solder termination make installation easy. With a high durability rating of 25,000 cycles and a wide operating temperature range from -40°C to 85°C, this switch is ideal for industrial and commercial use. Trust in the P4-424112 for efficient and dependable control in your applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
