| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-425122 |
| Series: | P4 |
| Cap Color: | Black |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Contact Material: | Silver |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | 3PDT 9 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP4-425122 |
P4-425122
Specifications
Detailed Description
Introducing the P4 Series Two Step Custom Pushbutton Switch, SKU P4-425122, designed for precision control in demanding environments. Featuring a sleek black aluminum housing with a panel mount configuration, this switch ensures durability and reliability with a 25,000 cycle lifespan. The button actuator, made of high-quality thermoplastic, offers a comfortable tactile response. Gold-plated contacts with a 3PDT 9 terminal configuration guarantee efficient signal transmission, while a 5A current rating and 28VDC voltage rating make it suitable for various applications. With a temperature range spanning from -40°C to 85°C, this sealed switch is ideal for use in both indoor and outdoor settings. Perfect for industrial, automotive, or aerospace use, the P4 Series Pushbutton Switch delivers high performance in a compact form factor.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
