| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-723115 |
| Series: | P4 |
| Cap Color: | Green |
| IP Rating: | IP6K4S |
| Case Color: | Silver |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | DPDT 6 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP4-723115 |
P4-723115
Specifications
Detailed Description
Introducing the P4 Series Auxiliary Actuators, a versatile solution for your switching needs. Featuring a sleek design with a flat green button and a durable silver aluminum case, these sealed push-button switches are perfect for panel mounting. With a current rating of 5A and a contact configuration of DPDT 6 Terminal, they offer reliable performance in various applications. The thermoplastic actuator ensures smooth operation, while the gold-plated brass contacts guarantee long-lasting conductivity. Rated for 25,000 cycles and with an IP6K4S ingress protection, these switches are built to withstand harsh environments. Whether for industrial machinery or consumer electronics, the P4 Series delivers precision control. Experience convenience and quality with these two-step custom pushbuttons, designed for momentary action.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
