| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-723117 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | DPDT 6 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Violet |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-723117 |
P4-723117
Specifications
Detailed Description
Introducing the P4 series Push Button Switch, SKU P4-723117, featuring a sleek design with a Violet cap and Silver case. With an IP6K4S rating, this sealed switch ensures reliable performance in various environments. The Button (Flat) actuator, made of Thermoplastic, offers a comfortable touch. Operating at 115 VAC or 28 VDC, with a current rating of 5A, it's suitable for diverse applications. Boasting DPDT 6 Terminal configuration, it provides versatile functionality. Gold-plated Brass contacts and Aluminum housing guarantee durability, with a 25,000 cycle lifespan. Ideal for panel mounting and solder termination, this switch is perfect for demanding industrial settings. Meeting high standards for quality and performance, it's the go-to choice for your switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
