| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-723119 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | DPDT 6 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | White |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-723119 |
P4-723119
Specifications
Detailed Description
Introducing the P4 series auxiliary actuator, SKU P4-723119, designed for reliable performance in demanding environments. With an IP6K4S sealing rating and durable construction, this push button switch ensures protection against dust and water ingress. Featuring a sleek silver case and a white flat button actuator, it offers a modern and ergonomic design. The DPDT 6 terminal configuration with gold-plated brass contacts guarantees high conductivity and longevity, even in high-voltage applications up to 115VAC and 28VDC. Ideal for panel mounting, its thermoplastic actuator material and aluminum housing provide excellent durability, with a rating of 25,000 cycles. From industrial machinery to transportation vehicles, this two-step custom push button switch is the perfect choice for critical operations in a wide range of industries.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
