| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-824221 |
| Series: | P4 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | DPDT 8 Terminal |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP4-824221 |
P4-824221
Specifications
Detailed Description
Introducing our P4 Series Two-Step Custom Pushbutton Switch, SKU P4-824221, designed for seamless panel mounting in industrial settings. Featuring a durable aluminum housing with a sleek black case and a vibrant red flat-button actuator, this switch ensures reliable performance in challenging environments. With an IP6K4S rating, it guarantees protection against dust and water ingress. The DPDT 8-terminal configuration with gold-plated brass contacts offers high conductivity and longevity, rated for 25,000 cycles. Operating at temperatures ranging from -40 to 85 °C, and with a current rating of 5A, it's suitable for various applications. Whether for machinery control or equipment operation, this sealed pushbutton switch is a dependable choice.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
