| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P5-115121 |
| Series: | P5 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .32 in |
| Switch Function: | Off-On |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP5-115121 |
P5-115121
Specifications
Detailed Description
Introducing the rugged and reliable P5 series Pushbutton Switch, SKU P5-115121. Designed for high-performance applications, this switch features a red button with a flat, round actuator for easy operation. The black aluminum housing ensures durability, while the thermoplastic actuator material offers excellent tactile feedback. With a current rating of 5A and a voltage rating of 115VAC / 28VDC, this switch is suitable for a wide range of industrial and military uses. Its sealed construction and Mil Grade certification guarantee optimal performance even in harsh environments. The SPST contact configuration and Off-On switch function provide straightforward control, making it ideal for mission-critical operations. Trust in the P5 Pushbutton Switch for dependable and consistent performance in any situation.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
