| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P5-D121328 |
| Series: | P5-D |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST |
| Actuator Type: | Button (Flush) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Gray |
| Actuator Length: | .48 in |
| Switch Function: | Off-On |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP5-D121328 |
P5-D121328
Specifications
Detailed Description
The P5-D Series P5-D121328 Push Button Switch features a durable and reliable design, perfect for high-stress environments. With an IP6K8S rating for water and dust resistance, this switch ensures optimal performance even in challenging conditions. The sleek black aluminum housing with a gray flush button provides a professional look while offering easy panel mounting. Operating at 115VAC or 28VDC, with a 5A current rating, it is suitable for various applications. The SPST contact configuration and Off-On switch function guarantee efficient control. Constructed with high-quality materials including silver-plated brass contacts, this sealed switch boasts a lifespan of 25,000 cycles. From industrial machinery to automotive systems, the P5-D121328 is a reliable solution for your switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
