| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P7-AA1112 |
| Series: | P7 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Raised) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .041 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 50,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP7-AA1112 |
P7-AA1112
Specifications
Detailed Description
The P7-AA1112 Pushbutton Switch, part of the P7 series, combines durability and reliability in a sleek design. Featuring a black button with a raised round actuator, this switch is perfect for panel mounting applications. With an IP6K4S rating, it offers protection against dust and water ingress, ensuring longevity. The SPST-NO contact configuration and 5A current rating make it suitable for various electrical circuits. Gold-plated brass contacts and a thermoplastic actuator ensure high performance even in demanding environments. Operating between -55°C to 85°C, it guarantees functionality in extreme temperatures. With a 50,000 cycle durability rating, this sealed pushbutton switch is a dependable choice for industrial and commercial use.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
