| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P7-AA1232 |
| Series: | P7 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Raised) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .17 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 50,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP7-AA1232 |
P7-AA1232
Specifications
Detailed Description
Introducing the P7 Subminiature Momentary Action Pushbutton Switch, a high-performance component designed for seamless panel mounting. With a sleek silver case and a black button, this switch not only boasts a sophisticated appearance but also features durability with a rating of 50,000 cycles. The SPST-NO contact configuration ensures reliable performance, while the gold-plated brass contacts guarantee optimal conductivity. Operating smoothly in temperatures ranging from -55°C to 85°C, this switch is suitable for a variety of environments. Whether used in industrial machinery or consumer electronics, its IP6K4S rating guarantees protection against dust and water ingress. The P7 is the ideal choice for applications that demand precision and longevity.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
