| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P7-AB1121 |
| Series: | P7 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Raised) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .17 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 50,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP7-AB1121 |
P7-AB1121
Specifications
Detailed Description
The P7-AB1121 Push Button Switch, part of the P7 series, boasts a striking red cap and a durable black aluminum case. Featuring a non-illuminated design, this sealed switch with an IP6K8S rating guarantees reliable performance in various environments. With a raised round button actuator made of thermoplastic and brass contacts plated in gold, it ensures tactile feedback and optimal conductivity. Operating at 115 VAC or 28 VDC, and with a 5A current rating, it's suitable for a range of applications. Its SPST-NO contact configuration and Off-(On) switch function make it ideal for momentary action control. Panel mount installation and solder termination offer easy integration. With a high durability rating of 50,000 cycles and a wide temperature range from -55°C to 85°C, this switch is a dependable choice for demanding industrial or commercial settings.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
