| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-311321E |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-311321E |
P8-311321E
Specifications
Detailed Description
Introducing the P8-311321E from the P8 series, a Subminiature Momentary Action Sealed Pushbutton Switch designed for durability and reliability. With a sleek red cap and silver case, this switch features a flat round button actuator made of thermoplastic, perfect for panel mounting. Its IP6K8S rating ensures protection against dust and water ingress, while the SPST-NO contact configuration and 10A current rating guarantee efficient operation. Ideal for industrial applications, this switch offers a wide operating temperature range from -55°C to 85°C and a high durability rating of 100,000 cycles. Whether used in automotive, aerospace, or machinery, the P8-311321E delivers precision control and long-lasting performance. Switch to excellence with this premium-grade pushbutton switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
