| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-331211A |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Quick Connect |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-331211A |
P8-331211A
Specifications
Detailed Description
Introducing the P8 series Subminiature Momentary Action Sealed Pushbutton Switch, SKU P8-331211A. This high-quality switch features a sleek design with a red flat round button and a durable silver aluminum housing. Perfect for panel mounting, it offers reliable performance with a contact rating of 10A. The SPST-NO contact configuration ensures seamless operation, with silver contacts and a brass contact material guaranteeing longevity. With a wide temperature range from -55°C to 85°C and IP6K4S rating, it is suitable for various environments. Whether for industrial, automotive, or consumer electronics applications, this switch delivers uncompromising quality and performance. Upgrade your control systems with the P8 pushbutton switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
