| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-341121A |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Unsealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-341121A |
P8-341121A
Specifications
Detailed Description
Introducing the P8 series Subminiature Momentary Action Sealed Pushbutton Switch, SKU P8-341121A. This high-quality switch features a sleek design with a red cap and black case, perfect for panel mounting. With a durable aluminum housing and thermoplastic actuator, it guarantees longevity even in demanding environments. The SPST-NO contact configuration and 10 A current rating ensure reliable performance. Ideal for industrial applications, it operates smoothly in temperatures ranging from -55 °C to 85 °C. With a contact plating of silver and 100,000 cycle durability rating, this switch offers exceptional quality and longevity. Whether for commercial or industrial use, this pushbutton switch is a trusted choice.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
