| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-351111A |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Unsealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-351111A |
P8-351111A
Specifications
Detailed Description
The P8-351111A Pushbutton Switch from the P8 series is a reliable choice for various applications. Featuring a red button with a flat round actuator, this switch is designed for panel mount installation in a sleek black aluminum case. With a non-illuminated design, it offers a durable actuation life of 100,000 cycles. The SPST-NO contact configuration, with a 10A current rating, ensures efficient power control. Operating at a wide temperature range from -55°C to 85°C, and compatible with both 115VAC and 28VDC, it suits diverse environments. The screw termination type and silver contact plating enhance connectivity and conductivity. Overall, this switch guarantees high performance and longevity in demanding industrial settings.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
