| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-351311B |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-351311B |
P8-351311B
Specifications
Detailed Description
Introducing the P8 Series Subminiature Momentary Action Sealed Pushbutton Switch, SKU P8-351311B. Featuring a sleek design with a vibrant red cap and durable black case, this switch is perfect for panel mounting applications. The button actuator, made of thermoplastic, offers a smooth round shape for comfortable operation. With a current rating of 10A, silver contact plating, and brass contact material, it guarantees reliable performance. Boasting a high durability rating of 100,000 cycles, it is built to last. Operating at temperatures ranging from -55°C to 85°C, with an IP6K8S rating for dust and water resistance, it ensures functionality in diverse environments. Ideal for industrial and commercial settings, this switch is essential for control and power applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
