| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-531111G |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Dome) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Quick Connect |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .187 in |
| Switch Function: | OFF-ON |
| Type: | Unsealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-531111G |
P8-531111G
Specifications
Detailed Description
Introducing the P8 Series Subminiature Momentary Action Sealed Pushbutton Switch, P8-531111G. This high-quality switch features a durable design with a red button actuator, perfect for panel mounting applications. With a 10A current rating and SPST-NO contact configuration, it ensures reliable performance. The silver contact plating and brass contact material guarantee efficient conductivity. Operating smoothly at temperatures ranging from -55°C to 85°C, it is suitable for various environments. With a 100,000 cycle durability rating, this switch offers long-lasting use. The P8 Series is ideal for applications where a reliable, non-illuminated pushbutton switch is required. Upgrade your control systems with this premium-quality component.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
