| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-621121C |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .187 in |
| Switch Function: | OFF-ON |
| Type: | Unsealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-621121C |
P8-621121C
Specifications
Detailed Description
Introducing the P8-621121C, a robust and reliable subminiature momentary action sealed pushbutton switch from the P8 series. Featuring a sleek design with a red button and silver case, this switch is perfect for panel mounting applications. With a high current rating of 10A and a durable construction rated for 100,000 cycles, it ensures long-lasting performance even in demanding environments. The SPST-NO contact configuration and brass contact material guarantee efficient and reliable operation. Whether you're in need of a dependable switch for industrial machinery or electronic devices, the P8-621121C is the ideal choice.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
