| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-651314A |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Yellow |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-651314A |
P8-651314A
Specifications
Detailed Description
Introducing the P8-651314A, from the P8 series. This pushbutton switch features a durable design with a yellow button cap and a black aluminum housing, perfect for demanding environments. With an IP6K8S rating, it offers reliable sealing against dust and moisture. The SPST-NO contact configuration, along with a 10 A current rating, ensures efficient performance. Suitable for panel mounting, its thermoplastic actuator and silver-plated brass contacts guarantee longevity, with a durability rating of 100,000 cycles. Operating between -55°C to 85°C, and compatible with both 115 VAC and 28 VDC, this switch is versatile and dependable. Ideal for industrial applications, the P8-651314A is a high-quality solution for your switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
