| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A141213 |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Low Profile Flat) |
| Case Color: | Black |
| Actuator Material: | Aluminum |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .079 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-A141213 |
P8-A141213
Specifications
Detailed Description
Introducing the P8-A141213, a rugged and reliable Vandal Resistant Pushbutton Switch designed for demanding environments. With a sleek Black cap and case, this switch is not only visually appealing but also IP6K4S rated for dust and water resistance. The low profile flat Button actuator ensures smooth operation, while the durable aluminum housing guarantees longevity, with a durability rating of 100,000 cycles. Ideal for panel mounting, this SPST-NO switch offers a 10A current rating and is suitable for both AC (115V) and DC (28V) applications. From industrial machinery to outdoor kiosks, the P8 series sets the standard for quality and performance in Push Button Switches.
