| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A142325 |
| Series: | P8 |
| Cap Color: | Black |
| IP Rating: | IP6K8S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flush) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-OFF |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Aluminum |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NC |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP8-A142325 |
P8-A142325
Specifications
Detailed Description
Introducing the P8 Series Vandal Resistant Pushbutton Switch, SKU P8-A142325. Designed for durability and reliability, this switch features a black aluminum housing and a flush-mount black button actuator, perfect for high-demand environments. With an IP6K8S rating, it ensures protection against dust and water ingress. The SPST-NC contact configuration, with silver-plated brass contacts, offers a secure connection. Operating at a wide temperature range from -55°C to 85°C, and with a current rating of 10A, it is suitable for various applications. Whether for industrial machinery or outdoor equipment, this sealed pushbutton switch guarantees long-lasting performance, with a 100,000-cycle durability rating. Trust in its quality for your control needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
