| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A341314 |
| Series: | P8 |
| Cap Color: | Black |
| IP Rating: | IP6K8S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Low Profile Curved) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .12 in |
| Contact Plating: | Silver |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Aluminum |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP8-A341314 |
P8-A341314
Specifications
Detailed Description
Introducing the Vandal Resistant Pushbutton Switch, the ultimate solution for durable and reliable panel-mounted control. Part of the P8 series, this switch boasts a sleek black aluminum housing and a low-profile curved button actuator for ergonomic use. With an IP6K8S rating, it ensures protection against dust and water ingress, making it perfect for outdoor and industrial applications. The SPST-NO configuration and 10A current rating guarantee efficient performance. Featuring a rugged design with a 100,000 cycle durability rating, this switch is built to last in harsh environments. Operating smoothly between -55°C and 85°C, it offers dependable functionality even in extreme temperatures. Trust in the P8A341314 for secure and long-lasting switching control.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
