| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A341513 |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Low Profile Flat) |
| Case Color: | Black |
| Actuator Material: | Aluminum |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .079 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-A341513 |
P8-A341513
Specifications
Detailed Description
Introducing the Vandal Resistant Pushbutton Switch, part of the P8 series. This durable switch features a sleek black design with a low-profile flat button actuator, perfect for panel mounting. With an IP6K8S rating, it ensures reliable performance even in harsh environments. The SPST-NO contact configuration, along with a 10A current rating, guarantees efficient operation. Crafted with high-quality materials including aluminum housing and actuator, and brass contacts with silver plating, this switch offers a lifespan of 100,000 cycles. Its wide operating temperature range from -55°C to 85°C, and voltage ratings of 115VAC and 28VDC, make it suitable for various applications. Upgrade your control systems with this premium-grade, sealed pushbutton switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
