| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A526313 |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPDT |
| Actuator Type: | Button (Low Profile Flat) |
| Case Color: | Silver |
| Actuator Material: | Aluminum |
| Termination Type: | Quick Connect |
| Actuator Shape: | Round |
| Cap Color: | Silver |
| Actuator Length: | .079 in |
| Switch Function: | ON-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-A526313 |
P8-A526313
Specifications
Detailed Description
Introducing the P8 Series Vandal Resistant Pushbutton Switch, boasting a sleek silver design perfect for panel mounting. This durable switch features a low profile flat button actuator with a round shape, ensuring reliable operation through 100,000 cycles. With an IP6K8S sealing rating, it offers robust protection against water and dust ingress. The SPDT contact configuration, rated for 10A at 115VAC and 28VDC, guarantees versatile functionality. Crafted from high-quality aluminum housing and actuator material, this switch is built to withstand harsh environments, with an operating temperature range of -55°C to 85°C. Ideal for applications requiring a secure and long-lasting user interface, the P8 Series sets a new standard for performance and reliability in pushbutton switches.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
