| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A552312 |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NC |
| Actuator Type: | Button (High Profile Curved) |
| Case Color: | Black |
| Actuator Material: | Aluminum |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .25 in |
| Switch Function: | ON-OFF |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-A552312 |
P8-A552312
Specifications
Detailed Description
Introducing the Vandal Resistant Pushbutton Switch from our P8 series, SKU P8-A552312. This durable and reliable switch features a high-profile curved button actuator for easy operation. With a black aluminum housing and IP6K8S sealing, it ensures robust performance in any environment. The SPST-NC contact configuration, rated for 10A at 115VAC and 28VDC, guarantees efficient power control. Ideal for panel mounting with screw termination, this switch is perfect for industrial applications where reliability is paramount. With a lifespan of 100,000 cycles and an operating temperature range from -55°C to 85°C, it's built to last. Upgrade to the P8A552312 for a dependable solution in critical switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
