| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A561213 |
| Series: | P8 |
| Cap Color: | Black |
| IP Rating: | IP6K4S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Low Profile Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .079 in |
| Contact Plating: | Silver |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Quick Connect |
| Actuator Material: | Aluminum |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP8-A561213 |
P8-A561213
Specifications
Detailed Description
Introducing the P8-A561213, a durable and reliable Vandal Resistant Pushbutton Switch designed for demanding environments. Featuring a sleek Black cap and case, this switch is not only stylish but also IP6K4S rated for robust protection against dust and water ingress. The Low Profile Flat Button actuator ensures a comfortable and smooth operation, while the SPST-NO contact configuration guarantees a reliable connection. With a high durability rating of 100,000 cycles, this switch is built to last. Ideal for panel mounting, it offers a maximum operating temperature of 85°C and a minimum of -55°C, making it suitable for a wide range of applications. Whether it's in industrial machinery or outdoor equipment, the P8-A561213 excels in performance and longevity.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
