| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P8-A561324 |
| Series: | P8 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Low Profile Curved) |
| Case Color: | Black |
| Actuator Material: | Aluminum |
| Termination Type: | Quick Connect |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .141 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP8-A561324 |
P8-A561324
Specifications
Detailed Description
Introducing the Vandal Resistant Pushbutton Switch ( P8-A561324) from the P8 series, designed for durability and reliability in demanding environments. Featuring a sleek black design with an IP6K8S rating, this switch is ideal for outdoor or industrial applications. The low-profile curved button actuator offers a comfortable user experience, while the SPST-NO contact configuration ensures efficient operation. With a 10A current rating and silver contact plating, it guarantees high performance over 100,000 cycles. Panel mountable with quick connect termination, installation is seamless. Operating from -55°C to 85°C and rated for 115VAC/28VDC, it's suitable for a wide range of voltage applications. Trust this P8 series switch for robust, long-lasting functionality in any setting.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
