P9-133126W

The P9-133126W Blue Sealed Dome Pushbutton Switch, part of the P9 series, is a reliable and durable component designed for demanding environments. With an IP6K8S rating for water and dust resistance, this switch ensures optimal performance even in harsh conditions. Featuring a Button (Flush Dome) actuator type with a round shape, it offers a comfortable and intuitive user experience. The gold-plated brass contacts guarantee efficient conductivity, while the thermoplastic housing and actuator material provide excellent durability. With a voltage rating of 115 VAC and 28 VDC, a current rating of 3A/5A, and a contact configuration of SPDT, this switch is suitable for a wide range of applications. Panel mountable with quick connect termination, it is easy to install. Operating temperature ranging from -40°C to 85°C, and a 25,000 cycle durability rating ensure long-term reliability. Whether used in industrial machinery, automotive systems, or aerospace applications, the P9-133126W is the ideal choice for sealed pushbutton switching needs.
