| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P9-511124W |
| Series: | P9 |
| Housing Material: | Thermoplastic (TP) |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flush Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Yellow |
| Actuator Length: | .101 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 3 A | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP9-511124W |
P9-511124W
Specifications
Detailed Description
Introducing the P9-511124W, a high-quality sealed dome pushbutton switch designed for durability and reliability. Featuring a yellow flush dome button, this switch is perfect for panel mounting applications, with an IP6K8S rating for dust and water resistance. The actuator is made of thermoplastic, ensuring longevity even in harsh environments. Gold-plated brass contacts offer excellent conductivity, with a switch function of Off-(On) and a contact configuration of SPST-NO. This switch can handle a current rating of 3A or 5A, with a voltage rating of 115VAC or 28VDC. Operating temperature ranges from -40°C to 85°C, making it suitable for a wide range of settings. With a 25,000 cycle durability rating, the P9-511124W is a reliable choice for industrial and commercial applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
