| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P9-623122W |
| Series: | P9 |
| Housing Material: | Thermoplastic (TP) |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPDT |
| Actuator Type: | Button (Raised Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .201 in |
| Switch Function: | ON-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Seal, PCB Mount |
| Current Rating: | 3 A | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP9-623122W |
P9-623122W
Specifications
Detailed Description
The P9-623122W, from the P9 series, is a rugged Sealed Dome Pushbutton Switch designed for reliable performance in demanding environments. With a sleek Black cap and case color, this switch features an IP6K8S rating for dust and water resistance. The Button (Raised Dome) actuator with a Round shape offers a tactile response, while the gold-plated contacts ensure efficient conductivity. Operating at 115 VAC and 28 VDC, with a current rating of 3A and 5A, this switch is suitable for a wide range of applications. Its SPDT contact configuration and On-(On) switch function provide versatility. Constructed with durable thermoplastic housing and actuator materials, and rated for 25,000 cycles, this switch guarantees long-lasting performance even in extreme temperatures ranging from -40°C to 85°C. Ideal for use in various industrial and commercial settings, the P9-623122W is a reliable choice for your switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
