| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P9-911122 |
| Series: | P9 |
| Housing Material: | Thermoplastic (TP) |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K4S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flush Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .09 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 3 A | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP9-911122 |
P9-911122
Specifications
Detailed Description
The P9-911122 Push Button Switch is a durable and reliable component designed for rugged environments. Featuring a black flush dome actuator and gold-plated brass contacts, this sealed switch ensures high performance with a 25,000-cycle durability rating. With an IP6K4S ingress protection rating, it guarantees resistance to dust and water, making it ideal for outdoor or industrial applications. Operating at temperatures ranging from -40°C to 85°C and accommodating both AC and DC voltages up to 115VAC and 28VDC, it offers versatility in usage. The SPST-NO contact configuration with a standard Off-(On) switch function provides straightforward control. Suitable for panel mounting with solder termination, this switch is a dependable choice for various electronic systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
