| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P9-A11222 |
| Series: | P9 |
| Cap Color: | Black |
| IP Rating: | IP6K4S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised Dome) |
| Actuator Shape: | Round |
| Current Rating: | 3 A | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .211 in |
| Contact Plating: | Gold |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Thermoplastic (TP) |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP9-A11222 |
P9-A11222
Specifications
Detailed Description
Introducing the P9-A11222, a durable and reliable Sealed Dome Pushbutton Switch designed for optimal performance in various applications. This black pushbutton switch features a raised dome button actuator with a round shape, ensuring comfortable and precise operation. With an IP6K4S rating and a sealed construction, it offers protection against dust and moisture, making it suitable for use in harsh environments. The switch has a gold contact plating on brass terminals, guaranteeing excellent conductivity and corrosion resistance. Operating at a maximum temperature of 85°C and a minimum of -40°C, it is built to withstand extreme conditions. Ideal for panel mounting, it has a current rating of 3A for AC and 5A for DC, with a voltage rating of 115VAC and 28VDC. The SPST-NO contact configuration and Off-(On) switch function provide reliable control. With a durability rating of 25,000 cycles, this switch ensures long-lasting performance. Perfect for industrial, automotive, and aerospace applications, the P9-A11222 is a high-quality solution for your switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
