| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P9M-211128 |
| Series: | P9M |
| Cap Color: | Gray |
| IP Rating: | IP6K8S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flush Dome) |
| Actuator Shape: | Round |
| Current Rating: | 4 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .38 in |
| Contact Plating: | Gold |
| Switch Function: | OFF-ON |
| Contact Material: | Silver |
| Housing Material: | Thermoplastic (TP) |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 200,000 Cycles |
| Voltage Rating (DC): | 12 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP9M-211128 |
P9M-211128
Specifications
Detailed Description
Introducing the P9M-211128, a rugged and reliable sealed latching pushbutton switch designed for demanding environments. With an IP6K8S rating, this switch ensures protection against dust and water ingress, making it ideal for outdoor and industrial applications. The gray flush dome button and black thermoplastic housing not only provide a sleek appearance but also guarantee durability with a 200,000 cycle lifespan. Featuring a SPST-NO contact configuration and gold-plated silver contacts, this switch offers excellent conductivity and reliability. Operating at a voltage rating of 12VDC and a current rating of 4A, it is suitable for a wide range of electronic devices. The P9M-211128 is panel mountable and has a solder termination type, facilitating easy installation. Whether used in automotive, marine, or aerospace systems, this pushbutton switch delivers uncompromising performance in any situation.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
