| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P9M-311122 |
| Series: | P9M |
| Housing Material: | Thermoplastic (TP) |
| Contact Material: | Silver |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flush Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .27 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 200,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 4 A |
| Voltage Rating (DC): | 12 VDC |
| SKU: | OTTP9M-311122 |
P9M-311122
Specifications
Detailed Description
The P9M-311122 is a high-performance sealed latching pushbutton switch designed for durability and reliability in demanding environments. Featuring a sleek black design with a flush dome button actuator, this switch is ideal for panel mounting applications. With an IP6K8S rating, it offers excellent protection against dust and water ingress. The gold-plated contacts ensure optimal conductivity, while the silver contact material guarantees long-lasting performance. Operating at a voltage of 12VDC and a current rating of 4A, this switch is suitable for a wide range of electronic devices. The SPST-NO contact configuration and Off-(On) switch function provide precise control. Constructed with thermoplastic housing and actuator materials, it can withstand temperatures ranging from -40°C to 85°C. With a durability rating of 200,000 cycles, this switch is built to last. Perfect for applications in aerospace, automotive, and industrial settings, the P9M-311122 is a reliable choice for your switching needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
