| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls PE-2111 |
| Series: | PE |
| Housing Material: | Aluminum |
| Contact Plating: | Silver Alloy |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 2 |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .136 in |
| Switch Function: | OFF-ON |
| Type: | Unsealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTPE-2111 |
PE-2111
Specifications
Detailed Description
Introducing the PE-2111, a Mil-PRF-8805/96 compliant pushbutton switch designed for high reliability applications. This rugged switch features a red button with a round actuator shape, perfect for easy and precise operation. With a durable aluminum housing and a thermoplastic actuator, it ensures longevity even in harsh environments. The SPST-NO contact configuration and 5A current rating make it suitable for various circuit control tasks. Rated for 25,000 cycles of operation, it guarantees consistent performance. Whether used in aerospace, defense, or industrial settings, this panel mount switch is a dependable choice. With a wide temperature range from -55°C to 85°C and voltage ratings of 115VAC and 28VDC, it offers versatility. Trust the PE2111 for reliable momentary action control in critical systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
