| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls PE2-11121 |
| Series: | PE2 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 6 |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPDT |
| Actuator Type: | Button |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .28 in |
| Switch Function: | ON-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 2 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTPE2-11121 |
PE2-11121
Specifications
Detailed Description
PE2-11121 is a rugged and reliable momentary action pushbutton switch designed for demanding applications. With RoHS compliance and MIL-PRF-8805/99 certification, this switch guarantees high performance and durability. Featuring a black aluminum housing and a black button, it is both aesthetically pleasing and functional. The SPDT contact configuration, silver contact plating, and brass contact material ensure efficient and reliable electrical connections. Operating in temperatures ranging from -55°C to 85°C, and with a voltage rating of 115VAC and 28VDC, it is suitable for a wide range of environments. Its panel mount design and solder termination make installation easy. Ideal for industrial, military, and aerospace use, the PE2-11121 is a top choice for those seeking a quality sealed pushbutton switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
