180-044-103L001

$TEX180_044_103L001$

Heilind Number:	TEX180-044-103L001
Manufacturer:	NorComp
Manufacturer Number:	180-044-103L001
Datasheet:	Datasheet
ECAD Model:

Description:

Male High-Density D-Sub 44 Position Straight Solder Cup

More >>

Specifications

Attribute	Value
Product Category:	D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:	NorComp
Manufacturer Part Number:	NorComp 180-044-103L001
Gender:	Plug
Series:	180
Mount Angle:	Straight
Shell Finish:	Nickel Plated
Current Rating:	3 A
Shell Material:	Steel
Contact Plating:	Gold Flash
Termination Method:	Solder Cup
Number of Positions:	44
Maximum Operating Temperature:	100 °C
Minimum Operating Temperature:	-50 °C
Signal Wire Size:	24 AWG
SKU:	TEX180-044-103L001

Detailed Description

Introducing the 180-044-103L001 Male High-Density D-Sub 44 Position Straight Solder Cup Connector, a reliable and high-performance solution for your connectivity needs. With gold flash contact plating, it ensures optimal signal transmission and durability. Operating between -50°C to 100°C, it offers versatility for various environments. The steel shell with nickel plating guarantees robustness and longevity. Suitable for 24 AWG signal wire size, it provides a secure connection. RoHS compliant and with a 3A current rating, it meets industry standards for environmental and performance requirements. Perfect for applications that demand efficiency and quality, this connector is a must-have in your toolkit.

Frequently Bought Together

Product	Part #	Description
	NorComp 5745173-2	CABLE CLAMP KIT,SZ 3
	NorComp L717SDE09P1ACH4R	SPRING LATCH 2/BAG
	NorComp L717SDE09POL2C309	FERRULE SPLIT RING, HD
	NorComp 43020-0801	Micro-Fit 3.0 Plug Housing, Dual Row, 8 Circuits, UL 94V-0, Low-Halogen, Black
	NorComp 43025-0200	Micro-Fit 3.0 Receptacle Housing, Dual Row, 2 Circuits, UL 94V-0, Low-Halogen, Black
	NorComp 43025-0600	Micro-Fit 3.0 Receptacle Housing, Dual Row, 6 Circuits, UL 94V-0, Low-Halogen, Black
	NorComp 43030-0012	Micro-Fit 3.0 Crimp Terminal, Female, with Select Gold (Au) Plated Phosphor Bronze Contact, 30-26 AWG
	NorComp 50079-8100	1.25mm Pitch PicoBlade Crimp Terminal, 26-28 AWG, Bag
$Product$	NorComp 180-044-203L001	Female High-Density D-Sub 44 Position Straight Solder Cup
